Reconstructor® provides many interaction styles to navigate in the 3D scene.
The navigation modes are selectable through the Navigation toolbar (placed on the right, most used commands) or by Navigation command in the top menu and are grouped by type:
In the contextual menu of items other commands are available:
|
Go to To center the 3D window to the bounding box of the model. The view point is computed so that to contain the whole bounding box in the viewport. Warning: this could place sometimes the model far away, with the effect that it seems not visible. Therefore increase the max depth in the Options. This tool is very useful when you have loaded many objects and want to go quickly and easily to a specific one. |
|
Center to local origin The view point is aligned to local coordinate frame of the model, with X rightwards, Y upwards and Z going out of the screen. |
Align to bounding box The view point is aligned to the desired face of the bounding box of the model. |
In View Parameters dialog you can customize advanced parameters of the current view by controlling how the “virtual eye” sees the 3D scene with all your models.
